GE-SR469-P5-HI-A20-E Motor management relay

1、 Product Overview
GE-SR469-P5-HI-A20-E is part of the SR469 motor management relay series, designed for medium voltage motors, providing integrated management and protection functions. It is made of high-quality materials and advanced technology, with high sensitivity and fast response, and can accurately detect and respond to the operating status of the motor.

2、 Main features
Comprehensive protection function: This relay has functions such as overload protection, short circuit protection, and phase loss protection. It can cut off the power supply in a timely manner when the motor or circuit is abnormal, effectively protecting the safe operation of the motor and circuit.
Easy to install and use: GE-SR469-P5-HI-A20-E is designed to be compact and easy to install. At the same time, its front panel is well-designed and easy to use, and users can configure and adjust it according to their needs.
Long lifespan and reliability: This relay is made of high temperature resistant and corrosion-resistant materials, which have a long service life and reliability, ensuring long-term stable operation.
Enhanced front panel: The front panel includes an RS-232 program port interface with a baud rate of 9600 and programmable up to 19200 baud. In addition, there is a pull-out handle that can be sealed to prevent any unauthorized movement or disassembly.
Large LCD display screen: The front panel is equipped with a large LCD display screen that can display 40 characters. Users can view diagnostic information such as tripping or alarms locally through this display screen.
Multiple indicator lights and buttons: The panel also features motor and output status indicators, device indicators, numeric keypad, control and programming keys, including reset, exit, and menu buttons, as well as numerical keys that allow users to change set values.
3、 Technical specifications
Control power supply: Provides 70-265VAC, 90-300VDC control power supply.
Phase CT secondary: Designed with a 5-ampere phase CT secondary winding.
Certification: Passed ISO, UL, CSA, CE and other certifications.
Humidity: 95% (non condensing).
Operation time: Output relay for 10 milliseconds.
Storage temperature: -40 ° C to+80 ° C.
Phase difference instantaneous timing accuracy:+50 milliseconds.
4、 Application Fields
GE-SR469-P5-HI-A20-E motor management relay is suitable for various types of motors and circuit control, and can be widely used in the following fields:

Industrial automation: In the field of industrial automation, motors are key components in many production processes. GE-SR469-P5-HI-A20-E can ensure that these motors operate within their normal range and provide timely protection against abnormal situations.
Power system: Motor protection devices are commonly used in power systems to ensure the safe operation of motors and related equipment. This includes power plants, substations, and distribution systems.
Oil and gas industry: Electric motors are widely used in oil fields and natural gas production, and GE-SR469-P5-HI-A20-E can be used to protect these motors from overload, short circuit, and other issues.
Chemical plants: In the chemical industry, motors are commonly used to drive various equipment. GE-SR469-P5-HI-A20-E can ensure the safe operation of these critical equipment.
Water treatment and sewage treatment: Electric motors are used in water treatment equipment such as pumps, and GE-SR469-P5-HI-A20-E can ensure the safe operation of these equipment under various working conditions.
Transportation system: Motor protection devices may be used in urban transportation systems, such as elevators, subways, and fans. GE-SR469-P5-HI-A20-E can provide reliable protection.
