1762-L24BXB Programmable Logic Controller (PLC) module

Input/output configuration:
Digital Input: With 10 standard 24V DC inputs and 4 fast 24V DC inputs, it can receive various digital signals and quickly and accurately monitor and perceive the status during the production process, suitable for control scenarios that require quick response.
Output type: It has 5 relay outputs and 4 24V DC FET (Field Effect Transistor) outputs, as well as 1 high-speed output. Relay output can be used to control high-power equipment and has good load driving capability; FET output is suitable for situations that require high output frequency and accuracy, and high-speed output can meet the control requirements for fast action.
Communication ability:
Equipped with an embedded 8-pin mini DIN communication port, supporting communication protocols such as DF1, DH-485, ASCII, Modbus, etc. This enables the module to efficiently exchange and communicate data with other devices, facilitating connection with the upper computer, human-machine interface (HMI), or other communication devices, and achieving centralized monitoring and management of the system.
Power requirement: Powered by an external 24V DC power supply to ensure stable operation of the controller. In industrial environments, 24V DC power supply is a commonly used type of power supply, which is easy to obtain and use, and has good stability and reliability.
Physical characteristics:
The size is relatively small, making it easy to install and integrate into various industrial automation systems. Its specific dimensions are a height of 90mm (including 104mm when the DIN buckle is opened), a width of 160mm, a depth of 87mm, and a weight of only 0.1kg. It will not occupy too much space and is convenient for layout in limited spaces such as control cabinets.
Working environment: The temperature range of the working environment is 0 to 55 degrees Celsius, which can adapt to a wide range of industrial temperature conditions. Whether in a room temperature workshop environment or a slightly higher temperature production site, stable performance can be maintained.
Application scenario: Suitable for small to medium-sized control systems, commonly used in industrial automation applications such as manufacturing, process control, packaging, logistics, etc. For example, it can play an important role in automation control of small production lines, monitoring and protection of equipment.

As a pioneer in technology, ABB has received an order from Transpower New Zealand to upgrade its high-voltage direct current (HVDC) transmission lines, which interconnect the transmission networks of the North and South Islands.

It is reported that this high-voltage direct current transmission line connecting the North Island and South Island of New Zealand is an important component of the country’s power grid system and also the power balance system between South Africa. ABB’s Ability MACH control system, as the brain or nerve center of the link, will become a key component of the upgrade.

It is reported that the population of the North Island of New Zealand is more than three times that of the South Island, and in addition to its picturesque scenery, it also provides a large amount of hydroelectric power. Therefore, the demand for electricity in the North Island has greatly increased and relies on the power supply in the South Island. The north-south high-voltage direct current transmission interconnection line, which is over 600 kilometers long, can efficiently transmit clean electricity to high demand areas. The line also plays an important role in the New Zealand electricity market by allowing electricity trading between two islands.

ABB has a historic involvement in this project. The first New Zealand HVDC transmission system was built by ABB (formerly ASEA) in 1965, which was also one of the world’s first HVDC transmission systems at that time. It was originally a bipolar 600 megawatt (MW) link with a mercury arc valve, until 1992 when the original equipment was connected in parallel to a single pole and ABB collaborated with it to debug a new thyristor pole, increasing the capacity to 1040 MW.

It is reported that this upgrade includes the upgrade of Valve 2, which is composed of electrodes, optical fibers, and valve control units based on the latest ABB Ability MACH control system. The upgrade will be completed in 2020, and its implementation will minimize the impact on the power grid and electricity trading market.

This upgrade will improve the reliability and availability of the power grid, thereby enhancing power safety and bringing clean energy to consumers, “said Claudio Facchin, President of ABB’s Power Grid Division.” This project reaffirms our strategic focus on services and commitment to integrating renewable energy, as well as the role of digital technology based on ABB’s capabilities, and consolidates our leading position in HVDC technology, becoming the preferred partner for achieving a stronger, smarter, and more environmentally friendly power grid

ABB pioneered high-voltage direct current transmission technology 60 years ago and has obtained approximately 120 high-voltage direct current transmission projects with a total installed capacity of over 130000 megawatts, accounting for about half of the global installation base.
