1756-EN2TXT Enhanced Ethernet Communication Module

1、 Basic parameters
Communication Protocol: Supports Ethernet communication protocols such as TCP/IP, UDP, etc., ensuring compatibility and efficient communication with other Ethernet devices.
Connection interface: usually has multiple Ethernet ports, which can be connected to different network devices to achieve flexible network topology.
Communication speed: It has a high communication speed and can meet the requirements of industrial automation systems for real-time data transmission.
2、 Performance characteristics
Enhanced performance:
Compared to standard Ethernet communication modules, 1756-EN2TXT may have higher processing power, larger cache space, or faster communication speed.
Can better cope with complex industrial automation application scenarios and improve the overall performance of the system.
High reliability:
Adopting high-quality electronic components and advanced manufacturing processes, it has good stability and anti-interference ability.
Equipped with fault diagnosis and alarm functions, able to promptly detect and handle communication faults, ensuring the reliable operation of the system.
Easy to configure and manage:
Through Rockwell Automation’s programming software, modules can be easily configured and managed.
Supporting network parameter settings, device address allocation, and other functions simplifies the installation and debugging process of the system.
Strong compatibility:
Compatible with other modules and devices in the ControlLogix series, it can be seamlessly integrated into existing control systems.
It can also communicate with Ethernet devices from other brands to achieve cross platform integration.
3、 Application scenarios
High performance industrial automation production line: In automated production lines that require high communication performance, 1756-EN2TXT can ensure fast data transmission and collaborative work between devices.
In the field of complex process control, it serves as a communication hub for real-time monitoring and control of a large number of parameters in complex process control systems in industries such as chemical, pharmaceutical, and power.
Remote monitoring and management: Through Ethernet connection, remote monitoring and management of industrial automation systems can be achieved, improving the reliability and maintainability of the system.
Distributed Control System: In a distributed control system, the 1756-EN2TXT module can serve as a high-performance communication node, connecting various dispersed control units to achieve centralized control and management.
In summary, the 1756-EN2TXT enhanced Ethernet communication module provides a more powerful Ethernet communication solution for industrial automation systems in Rockwell Automation’s ControlLogix series.

As a pioneer in technology, ABB has received an order from Transpower New Zealand to upgrade its high-voltage direct current (HVDC) transmission lines, which interconnect the transmission networks of the North and South Islands.

It is reported that this high-voltage direct current transmission line connecting the North Island and South Island of New Zealand is an important component of the country’s power grid system and also the power balance system between South Africa. ABB’s Ability MACH control system, as the brain or nerve center of the link, will become a key component of the upgrade.

It is reported that the population of the North Island of New Zealand is more than three times that of the South Island, and in addition to its picturesque scenery, it also provides a large amount of hydroelectric power. Therefore, the demand for electricity in the North Island has greatly increased and relies on the power supply in the South Island. The north-south high-voltage direct current transmission interconnection line, which is over 600 kilometers long, can efficiently transmit clean electricity to high demand areas. The line also plays an important role in the New Zealand electricity market by allowing electricity trading between two islands.

ABB has a historic involvement in this project. The first New Zealand HVDC transmission system was built by ABB (formerly ASEA) in 1965, which was also one of the world’s first HVDC transmission systems at that time. It was originally a bipolar 600 megawatt (MW) link with a mercury arc valve, until 1992 when the original equipment was connected in parallel to a single pole and ABB collaborated with it to debug a new thyristor pole, increasing the capacity to 1040 MW.

It is reported that this upgrade includes the upgrade of Valve 2, which is composed of electrodes, optical fibers, and valve control units based on the latest ABB Ability MACH control system. The upgrade will be completed in 2020, and its implementation will minimize the impact on the power grid and electricity trading market.

This upgrade will improve the reliability and availability of the power grid, thereby enhancing power safety and bringing clean energy to consumers, “said Claudio Facchin, President of ABB’s Power Grid Division.” This project reaffirms our strategic focus on services and commitment to integrating renewable energy, as well as the role of digital technology based on ABB’s capabilities, and consolidates our leading position in HVDC technology, becoming the preferred partner for achieving a stronger, smarter, and more environmentally friendly power grid

ABB pioneered high-voltage direct current transmission technology 60 years ago and has obtained approximately 120 high-voltage direct current transmission projects with a total installed capacity of over 130000 megawatts, accounting for about half of the global installation base.
