1756-A7 Seven slot chassis

Physical structure:
Size: The physical size is 50.8×60.9×20.3 centimeters (20x24x8 inches), which is a relatively compact chassis that is easy to install and use in various space limited environments.
Weight: Approximately 1.10 kilograms (2.4 pounds), relatively lightweight, easy to handle and install.
Installation method: Install directly onto the sub panel of the cabinet using the four provided mounting tabs, with two mounting tabs at the top and two at the bottom. If SEM screws are not installed, in addition to two flat washers and two locking washers, two star washers are also required; If used together with SEM screws, only two cross screws are required.
Shell: Open shell, convenient for users to install and maintain internal modules, but also means it does not have an additional protective shell.
Power related:
Power slot: equipped with a power installation slot, located on the leftmost side of the chassis, supporting the installation of ultra-thin, standard, and power modules.
Power consumption: The power consumption is 4.5 watts, and in terms of backplane current supply, it can provide 1.5A@1.2Vdc The 4A@3.3Vdc The chassis/slot is 15A/ 6A@5.1Vdc And 2.8A/ 2.8A@24Vdc The current.
Work environment:
Temperature: The working temperature range is 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit), and it is recommended to store within a temperature range of -40 to 85 degrees Celsius to adapt to a wide range of temperature environments. However, in practical applications, it should be ensured that it operates within the appropriate temperature range to ensure performance and stability.
Humidity: The compatible humidity type is non condensing, and the relative humidity level that the chassis can use is 5% to 95%, with good humidity resistance. However, it is still important to avoid prolonged use in high humidity environments where condensation may occur.
Impact level: The impact level of the chassis in working condition is 30g (acceleration), and in non working condition, the impact level is 50g (acceleration). It has a certain impact resistance and can work stably in some industrial environments with certain vibrations and impacts.
Grounding setting:
Equipped with functional grounding and protective grounding terminals. The recommended wire type and size for functional grounding is 8.3 square millimeters (8AWG) solid copper wire or stranded copper wire, with an insulation level of 90 ° C (194 ° F) or higher; For protective grounding terminals, the appropriate wire size is 2.1 square millimeters (14AWG) solid or stranded copper wire with an insulation level of 90 ° C (194 ° F) or higher.
The 1756-A7 chassis, as an important component of the ControlLogix Programmable Automation Controller (PAC) platform, provides backplane connections and installation space for various modules, and is widely used in industrial automation fields such as manufacturing, energy, and transportation. In practical applications, users can install corresponding modules on their slots according to specific control requirements, and build control systems that meet specific functional requirements.
