1746-IB16 Digital input module

1、 Basic parameters
Number of input channels: 16 channels.
Input type: usually DC input, can accept high-level or low-level signals.
Input voltage range: The common input voltage range is 24V DC.
Isolation method: It has electrical isolation function to improve the anti-interference ability and safety of the system.
2、 Performance characteristics
High reliability:
By using high-quality electronic components and advanced manufacturing processes, the module ensures stable operation in harsh industrial environments.
It has functions such as overvoltage protection and overcurrent protection to prevent damage to the module caused by abnormal input signals.
Quick response:
Capable of quickly detecting changes in input signals and transmitting them to the control system for real-time control.
Short response time, meeting the high requirements for system response speed in application scenarios.
Easy to install and maintain:
The installation method is simple and can be directly installed on standard guide rails.
Equipped with diagnostic functions, it facilitates users to quickly locate and solve problems.
Strong compatibility:
It has good compatibility with other controllers and modules of Rockwell Automation and can form a complete automation control system.
3、 Application scenarios
Industrial automation production line: used to detect signals from various sensors, such as proximity switches, photoelectric switches, etc., to achieve automated control of the production process.
Mechanical equipment control system: receives input signals from buttons, limit switches, and other devices to control the operation of mechanical equipment.
Intelligent building system: used in intelligent buildings to monitor the status of various devices, such as door magnets, window magnets, etc., to achieve intelligent management.
In summary, the 1746-IB16 digital input module has been widely used in industrial automation and other fields due to its high reliability, fast response, easy installation and maintenance, and strong compatibility.

As a pioneer in technology, ABB has received an order from Transpower New Zealand to upgrade its high-voltage direct current (HVDC) transmission lines, which interconnect the transmission networks of the North and South Islands.

It is reported that this high-voltage direct current transmission line connecting the North Island and South Island of New Zealand is an important component of the country’s power grid system and also the power balance system between South Africa. ABB’s Ability MACH control system, as the brain or nerve center of the link, will become a key component of the upgrade.

It is reported that the population of the North Island of New Zealand is more than three times that of the South Island, and in addition to its picturesque scenery, it also provides a large amount of hydroelectric power. Therefore, the demand for electricity in the North Island has greatly increased and relies on the power supply in the South Island. The north-south high-voltage direct current transmission interconnection line, which is over 600 kilometers long, can efficiently transmit clean electricity to high demand areas. The line also plays an important role in the New Zealand electricity market by allowing electricity trading between two islands.

ABB has a historic involvement in this project. The first New Zealand HVDC transmission system was built by ABB (formerly ASEA) in 1965, which was also one of the world’s first HVDC transmission systems at that time. It was originally a bipolar 600 megawatt (MW) link with a mercury arc valve, until 1992 when the original equipment was connected in parallel to a single pole and ABB collaborated with it to debug a new thyristor pole, increasing the capacity to 1040 MW.

It is reported that this upgrade includes the upgrade of Valve 2, which is composed of electrodes, optical fibers, and valve control units based on the latest ABB Ability MACH control system. The upgrade will be completed in 2020, and its implementation will minimize the impact on the power grid and electricity trading market.

This upgrade will improve the reliability and availability of the power grid, thereby enhancing power safety and bringing clean energy to consumers, “said Claudio Facchin, President of ABB’s Power Grid Division.” This project reaffirms our strategic focus on services and commitment to integrating renewable energy, as well as the role of digital technology based on ABB’s capabilities, and consolidates our leading position in HVDC technology, becoming the preferred partner for achieving a stronger, smarter, and more environmentally friendly power grid

ABB pioneered high-voltage direct current transmission technology 60 years ago and has obtained approximately 120 high-voltage direct current transmission projects with a total installed capacity of over 130000 megawatts, accounting for about half of the global installation base.

Xiamen Xiongba E-commerce Co., Ltd. is a spare parts service provider in the field of industrial automation. Our main products include PLC modules, DCS cards, ESD system cards, vibration monitoring system cards, turbine control system modules, and gas generator spare parts. We have established close cooperative relationships with multiple PLC and DCS product maintenance service providers. The company operates in an e-commerce model, reduces intermediate links, and provides consumers with high-quality products and satisfactory services in a timely manner. The company has a complete logistics supply system and has established good cooperative relationships with many well-known foreign brand manufacturers. Our company can directly purchase goods from overseas, provide equipment and spare parts from different countries and manufacturers, and solve your troubles or concerns about product quality in multiple places. We have a great advantage in terms of price and detailed product information. We sincerely welcome you to call or use email to inquire! The company’s distributed products are widely used in industries such as CNC mechanical metallurgy, oil and gas, petrochemicals, chemical engineering, paper and printing, textile printing and dyeing, machinery, electronics manufacturing, automobile manufacturing, tobacco, plastic machinery, electricity, water conservancy, water treatment/environmental protection, municipal engineering, boiler heating, energy, and power transmission and distribution.
