1734-IB4 POINT I/O digital DC current input module

1、 Product Overview
Model: 1734-IB4
Brand: Allen Bradley (Rockwell Automation)
Type: POINT I/O Digital DC Current Input Module
Features: It has 4 current input channels and can be used with any POINT I/O communication adapter and POINT Block I/O module to achieve a distributed I/O architecture.
2、 Main specifications and characteristics
Input channel:
Quantity: 4
Type: Current input
Supporting voltage: 12/24VDC
Electrical parameters:
Maximum input current: 5mA
Power consumption: 1W
Heat dissipation: 3.4 BTU/hr
POINT Bus current (75V DC): 5mA
On site power supply voltage range: 10-28.8V DC
Isolation voltage: 50V (continuous)
Minimum conduction state voltage: 10V DC
Nominal conduction voltage: 24V DC
Maximum conduction state voltage: 28.8V DC
Minimum conduction current: 2mA
Nominal conduction current: 4mA
Maximum turn off voltage: 5V DC
Minimum shutdown current: 1.5mA
Physical characteristics:
Size: 56 x 12 x 75.5 millimeters (2.2 x 0.47 x 2.97 inches)
Weight: Approximately 31.8 grams (1.12 ounces)
Installation method: DIN rail installation, using zinc plate, yellow chromate steel DIN rail
Wiring method: All cables are connected to the detachable terminal block (RTB) installed at the bottom of the installation
indicator light:
Quantity: 4 yellow input status indicator lights
Function: Indicate module status, network status, input 0, 1, 2, and 3 status
Compatibility and Application:
Compatibility: Can be used with any POINT I/O communication adapter and POINT Block I/O module
Application: Mainly used in large-scale industries such as cement, petroleum, mining, steel, and shipbuilding, to implement distributed I/O applications for systems based on programmable logic controllers (PLCs)
