1394-AM04 ControlLogix controller

1、 Basic Information
Brand: Allen Bradley
Model: 1394-AM04
Type: ControlLogix controller, belonging to the ControlLogix 555 series
2、 Technical features
Memory configuration:
Although the controller does not have non-volatile memory, it has 5KB of data and logic memory, as well as 15KB of I/O memory, which is sufficient to meet the control requirements of a certain scale.
Installation and compatibility:
Users can install the controller in available chassis slots, and the controller is designed with an open housing for easy installation and maintenance.
This controller is compatible with specific models of serial cables (such as 1756-CP3) to ensure reliable and stable communication.
Electrical and environmental parameters:
The working temperature range may vary depending on the specific model, but generally has a wide working temperature range.
Has certain anti vibration and anti impact capabilities, suitable for the complex environment of industrial sites.
Interface and Communication:
Equipped with RS-232 interface, supporting multiple communication protocols (such as DeviceNet, Profinet, etc.), enabling information exchange between PLCs, PLCs and upper computers, and other intelligent devices, achieving decentralized and centralized control.
Programming and Monitoring:
By using a graphical programming interface, programming software is easy to learn and use, allowing engineers to develop programs faster.
Supports multiple programming languages (such as Structured Text, Instruction List, Sequential Function Chart, etc.) to meet the programming needs of different users.
Support real-time monitoring function, which can promptly detect problems in the system and take corresponding measures to solve them.
3、 Application Fields
1394-AM04 is widely used in various fields such as industrial automation, motion control, robotics technology, mechanical design, testing and measurement, packaging, pharmaceuticals, food and beverage, etc. With its powerful control capability and flexible communication interface, it can effectively collect, transmit production and management data, improve production efficiency and system stability.
4、 Summary
1394-AM04, as an Allen Bradley ControlLogix controller, has become an important product in the field of industrial automation due to its advanced technical features, wide compatibility, and flexible application areas. It has demonstrated excellent performance and reliability in complex production line control, precise motion control, and efficient data communication.

As a pioneer in technology, ABB has received an order from Transpower New Zealand to upgrade its high-voltage direct current (HVDC) transmission lines, which interconnect the transmission networks of the North and South Islands.

It is reported that this high-voltage direct current transmission line connecting the North Island and South Island of New Zealand is an important component of the country’s power grid system and also the power balance system between South Africa. ABB’s Ability MACH control system, as the brain or nerve center of the link, will become a key component of the upgrade.

It is reported that the population of the North Island of New Zealand is more than three times that of the South Island, and in addition to its picturesque scenery, it also provides a large amount of hydroelectric power. Therefore, the demand for electricity in the North Island has greatly increased and relies on the power supply in the South Island. The north-south high-voltage direct current transmission interconnection line, which is over 600 kilometers long, can efficiently transmit clean electricity to high demand areas. The line also plays an important role in the New Zealand electricity market by allowing electricity trading between two islands.

ABB has a historic involvement in this project. The first New Zealand HVDC transmission system was built by ABB (formerly ASEA) in 1965, which was also one of the world’s first HVDC transmission systems at that time. It was originally a bipolar 600 megawatt (MW) link with a mercury arc valve, until 1992 when the original equipment was connected in parallel to a single pole and ABB collaborated with it to debug a new thyristor pole, increasing the capacity to 1040 MW.

It is reported that this upgrade includes the upgrade of Valve 2, which is composed of electrodes, optical fibers, and valve control units based on the latest ABB Ability MACH control system. The upgrade will be completed in 2020, and its implementation will minimize the impact on the power grid and electricity trading market.

This upgrade will improve the reliability and availability of the power grid, thereby enhancing power safety and bringing clean energy to consumers, “said Claudio Facchin, President of ABB’s Power Grid Division.” This project reaffirms our strategic focus on services and commitment to integrating renewable energy, as well as the role of digital technology based on ABB’s capabilities, and consolidates our leading position in HVDC technology, becoming the preferred partner for achieving a stronger, smarter, and more environmentally friendly power grid

ABB pioneered high-voltage direct current transmission technology 60 years ago and has obtained approximately 120 high-voltage direct current transmission projects with a total installed capacity of over 130000 megawatts, accounting for about half of the global installation base.
