BENTLY 350022M 138607-01 Transient Data Interface (TDI) module

1、 Product Overview
Model: BENTLY 3500/22M 138607-01
Type: Transient Data Interface (TDI) module
Brand: Bently Nevada
Application areas: industrial automation, mechanical monitoring, vibration analysis, etc
2、 Main functions and features
High performance data collection:
Support high-speed data acquisition and transmission to meet the real-time and accuracy requirements of industrial monitoring applications.
Easy to use:
The module has a simple wiring method and clear indicator lights, making it easy to install and use. Users can quickly get started, reducing maintenance costs and time.
High reliability:
Using high-quality components and advanced manufacturing processes to ensure long-term reliable operation. Even in harsh industrial environments, it can maintain stable performance.
Data transmission capability:
Connect to System 1 through Ethernet interface ™ Mechanical management software connection enables fast data transmission and real-time analysis. The data transmission rate can reach up to 100 Mbps, meeting the needs of large data transmission.
Transient data capture:
It can collect transient data such as bearing vibration, temperature, pressure, etc., providing important basis for equipment status monitoring and fault diagnosis.
Fault warning and diagnosis:
Based on the analysis of transient data, issue fault warnings to help users prevent faults from occurring. At the same time, it provides fault diagnosis function to shorten the troubleshooting time.
Widely applicable fields:
Suitable for multiple fields such as discrete manufacturing, process industry, and power systems, it can be used to monitor various rotating machinery such as motors, pumps, compressors, fans, and steam turbines.
3、 Technical specifications
Interface type: Ethernet
Data transmission rate: 100 Mbps
Compatibility: Bently Nevada 3500 Monitoring System, System 1 ™ Mechanical Management Software
Protection level: IP20
Working temperature: -20 ° C to+55 ° C
Dimensions: 115 mm x 60 mm x 22 mm
