ABB REG216 Digital generator protection module

1、 Product Overview
Brand: ABB
Model: REG216
Type: Digital Generator Protection Module
Application scenarios: Widely used in various types of generator sets to ensure the safe operation of generators under various working conditions.
2、 Main features
Modular design:
REG216 adopts a modular design, which enables both hardware and software to have high flexibility and scalability. Users can easily add or remove functional modules according to their actual needs to adapt to the needs of different scales and application scenarios.
Comprehensive protection function:
Provide comprehensive generator protection functions, including but not limited to overcurrent protection, undervoltage protection, overvoltage protection, reverse power protection, etc. These functions can effectively prevent generator malfunctions during operation and ensure the stable operation of the system.
Quick response:
The differential protection technology based on the principle of vector product can maintain high stability and act quickly during transient faults and CT saturation. The differential protection action time is less than 30ms, effectively protecting the generator from damage.
High reliability and stability:
Adopting advanced digital technology to accurately process and analyze signals, ensuring the accuracy and reliability of protection. At the same time, REG216 is also equipped with comprehensive self checking and self diagnostic functions, which can timely detect and handle potential faults, improving the reliability of the entire system.
Easy to maintain:
Featuring a user-friendly interface, it is convenient for users to set parameters, configure functions, and diagnose faults. Through the interface, users can intuitively understand the operating status and fault information of the module, facilitating maintenance and troubleshooting.
Multiple communication protocols:
Supports multiple communication protocols such as Modbus, Profibus, etc., facilitating data exchange and communication with other control systems. This enables REG216 to be easily integrated into existing automation systems, achieving seamless system connectivity.
3、 Hardware composition
The REG216 device consists of two main components that are physically separated from each other and connected by standard prefabricated shielded cables:
Main system interfaces (CT, PT, and auxiliary relays): provide DC isolation and electromagnetic interference barriers.
Parallel bus and related electronic units: such as analog inputs and data processors/used for signal conditioning and processing.
Each device framework can provide 21 rack spaces, and all hardware can be installed in one compartment to further shield against inductive interference and provide physical protection such as dust prevention.
4、 Application scenarios
The ABB REG216 digital generator protection module is suitable for various types of generator sets, including but not limited to thermal power generation, hydropower generation, wind power generation, etc. Its high flexibility and scalability enable it to meet the needs of different scales and application scenarios, providing strong guarantees for the safe operation of generators.
In summary, ABB REG216 is a powerful, reliable, and flexible generator protection product. By selecting this module, users can achieve comprehensive protection of the generator set, improving the stability and reliability of the power generation system.
