PFTL301E 3BSE019050R1000 1.0KN cable

essential information
Model: PFTL301E 3BSE019050R1000 1.0KN
Brand: ABB
Series: FTL301
Functions and Applications
Main function: Used to convert analog signals into digital signals and provide isolation and amplification functions. This enables signals from sensors, transmitters, and other analog devices to be effectively processed by PLCs or other controllers.
Application areas: Suitable for various industrial applications, including process control, discrete manufacturing, machine vision, motion control, building automation, etc.
technical parameter
Input range: -10V to 10V or 4mA to 20mA
Output range: 0V to 10V or 4mA to 20mA
Accuracy: ± 0.1% of full scale
Resolution: 16 bits
Update rate: 250 Hz
Power supply range: 24 VDC
Power consumption:<5W
Working temperature: -40 ℃ to 85 ℃
Protection level: IP67 (for input interface part), IP65 for tension sensor part
Size: For the input interface, the size is 115mm × 75mm × 35mm; For the tension sensor, the dimensions are 380mm × 235mm × 90mm
Weight: For the input interface, the weight is 0.4kg; For tension sensors, the weight is 5kg+7.4kg (or 2.5kg separately, depending on the description)
Specific applications
Temperature control system: used to convert temperature signals from thermocouples or RTDs into digital signals so that the controller can adjust the heating or cooling system.
Pressure control system: used to convert pressure signals from pressure sensors into digital signals so that the controller can adjust valves or pumps.
Flow control system: used to convert flow signals from flow meters into digital signals so that the controller can adjust valves or pumps.
Position control system: used to convert position signals from position sensors into digital signals so that the controller can control servo motors or hydraulic cylinders.
Vibration monitoring system: used to convert vibration signals from vibration sensors into digital signals so that the controller can detect and analyze vibrations.
