PFTL101B 5.0KN 3BSE004191R1 Pressure magnetic tension sensor

1、 Product Overview
Model: PFTL101B 5.0KN 3BSE004191R1
Type: Magnetic Tension Sensor
Manufacturer: ABB
Purpose: Mainly used for tension measurement in industrial processes, especially in situations that require precise control and monitoring, such as material mechanical property testing, mechanical manufacturing, and automation control.
2、 Main features
High precision: This sensor has a high precision level, excellent linearity and repeatability, and can provide accurate weight data to meet the measurement needs of different parameters in industrial processes.
High reliability: The sensor is made of high-strength materials such as stainless steel and alloy steel, which have good durability and reliability. It can cope with various harsh conditions such as high temperature, low temperature, high humidity, low pressure, salt spray and hazardous gases, as well as vibration and impact, ensuring stable operation in industrial environments.
Wide applicability: This sensor can be hard connected to any flow meter, providing voltage, current, or Bluetooth connection readings, suitable for various application scenarios. At the same time, its high protection level of IP67 means that it has good dust and water resistance, and can work normally in harsh environments.
Multiple output options: The PFTL101B 5.0KN analog output sensor has a large input range of 0.25Hz to 5000 Hz and offers five user selectable outputs, including 4-20mA, 0-5V, 1-5V, 0-10V, and 2-10V, to meet the needs of different systems.
Remote programming and traffic monitoring: Through Bluetooth interface, users can perform remote programming and traffic monitoring through their smartphones, improving the convenience of operation.
3、 Technical specifications
Range: 5.0KN (500 kg force)
Material: High strength materials such as stainless steel and alloy steel
Protection level: IP67
Working temperature range: -40 ℃ to+85 ℃
Volume: 25mm x 25mm x 100mm
Weight: Approximately 0.5kg
4、 Application Fields
The PFTL101B 5.0KN 3BSE004191R1 sensor is widely used in multiple industrial fields, including but not limited to:
Mechanical manufacturing: used to measure and control the tension of mechanical components, ensuring the stability and safety of mechanical operation.
Automated control: used on automated production lines to monitor and control the tension of materials, ensuring the smooth progress of the production process.
Material mechanical performance testing: In a material testing machine, it is used as a component of the testing equipment to measure the mechanical properties of materials.
Food industry: used for detecting the weight of packaging materials and containers.
Chemical industry: used for weighing and monitoring the weight of liquids and solids.
Logistics field: used for weighing and monitoring the weight of goods during transportation.

Recently, ABB Group, headquartered in Switzerland, has attracted industry attention for a technology called “Flash Charging”. According to the information obtained from ABB (China) Enterprise Communication Department, “This technology was designed to be promoted globally

The system has been operating on the route between Geneva Airport and Palexpo Exhibition Center since May 26th and will continue until March 14th, 2014. The head of the company stated that this technology is suitable for ordinary cities, large cities, and mega cities seeking sustainable public transportation solutions. Used for high-frequency bus routes to alleviate traffic congestion in urban areas

According to ABB, this technology is equipped with a water-cooled lithium titanate oxide LTO battery pack with a service life of 10 years. There is a rooftop charging system at the station that can charge for 15 seconds at a power of 400 kilowatts. These charging systems are connected to the power grid and equipped with intermediate storage devices (supercapacitors) to reduce the impact of short-term high power on the grid. The fast charging point can charge buses up to 1.65 kWh. In addition, at the bus terminal, there is a 200 kW charger that can fully charge the battery in 3-4 minutes.

At present, pure electric buses using this technology can carry 135 people. When the vehicle stops at the station, it is located by infrared, and the charging point on the roof is connected to the moving arm controlled by laser after positioning. After completing a 15 second recharge, the vehicle continues to move forward without affecting the normal operation of the bus. Its concept is similar to that of a tram, but it does not require the installation of a complex network.

In addition to ABB, similar concepts of fast charging during driving are also being promoted by many companies in China. During an interview with reporters, Wang Binggang, the leader of the supervision and consulting expert group for the National 863 Program’s major projects on energy conservation and new energy vehicles, referred to this mode as “online charging” The online charging mode can effectively solve the contradiction between battery quantity and range Wang Binggang stated. It is reported that currently, bus companies such as Hunan CSR Times Electric Vehicle, Youth Bus, and Hengtong Electric Vehicle are developing and promoting similar technologies.

As a Fortune 500 company, ABB’s business scope includes power and automation technology. In the field of electric vehicles in China, ABB is a supplier of DC drives, motors, programmable controller products, electric vehicle charging infrastructure, and energy storage products. In the field of charging infrastructure, ABB has not had a good opportunity, perhaps the latest “flash charging technology” can find some market space for ABB.
