PFTL101A 3BSE004160R1 Load cell

1、 Product Overview
PFTL11013BSE004160R1, as one of ABB’s tension measurement series products, has high reliability and accuracy, and can meet the tension measurement needs of various industrial occasions. This sensor combines ABB’s advanced technologies, such as piezoelectric sensor technology and pulsed eddy current technology (PEC), to ensure the accuracy and stability of measurement results.
2、 Main features
Easy to install: PFTL11013BSE004160R1 is designed as an industrial grade electronic device, making it easy to install and deploy in various environments. The bottom of its control device is equipped with a pluggable screw terminal block, making cable connection simple and fast.
High temperature operation: This sensor has excellent high temperature resistance, with an operating temperature of up to 70 ° C, and can maintain a stable working state in high temperature environments.
Compliant with EMC standards: No additional casing is required to meet electromagnetic compatibility (EMC) standards, reducing the complexity of installation and maintenance.
Multiple measurement modes: Provides predetermined standard measurement modes, allowing users to easily configure analog/digital input/output ports as needed to meet different measurement needs.
Easy to debug and maintain: The sensor is equipped with a self diagnostic testing system, including sensor testing functions, making it convenient for users to troubleshoot and maintain. At the same time, parameter import and export can be set through PC, supporting network connection, and achieving remote access and monitoring.
High precision measurement: based on ABB’s patented technology, such as Presductor ® The pressure magnetic sensor and pulse eddy current technology (PEC) ensure the accuracy and reliability of the measurement results.
3、 Application Fields
PFTL11013BSE004160R1 is widely used in industrial applications that require precise tension measurement, such as steel, metallurgy, papermaking, textiles, and other industries. In the hot rolling mill, it can serve as a key component for measuring the loop tension, ensuring stable tension of the strip steel during production and improving product quality and production efficiency.

Recently, ABB Group, headquartered in Switzerland, has attracted industry attention for a technology called “Flash Charging”. According to the information obtained from ABB (China) Enterprise Communication Department, “This technology was designed to be promoted globally

The system has been operating on the route between Geneva Airport and Palexpo Exhibition Center since May 26th and will continue until March 14th, 2014. The head of the company stated that this technology is suitable for ordinary cities, large cities, and mega cities seeking sustainable public transportation solutions. Used for high-frequency bus routes to alleviate traffic congestion in urban areas

According to ABB, this technology is equipped with a water-cooled lithium titanate oxide LTO battery pack with a service life of 10 years. There is a rooftop charging system at the station that can charge for 15 seconds at a power of 400 kilowatts. These charging systems are connected to the power grid and equipped with intermediate storage devices (supercapacitors) to reduce the impact of short-term high power on the grid. The fast charging point can charge buses up to 1.65 kWh. In addition, at the bus terminal, there is a 200 kW charger that can fully charge the battery in 3-4 minutes.

At present, pure electric buses using this technology can carry 135 people. When the vehicle stops at the station, it is located by infrared, and the charging point on the roof is connected to the moving arm controlled by laser after positioning. After completing a 15 second recharge, the vehicle continues to move forward without affecting the normal operation of the bus. Its concept is similar to that of a tram, but it does not require the installation of a complex network.

In addition to ABB, similar concepts of fast charging during driving are also being promoted by many companies in China. During an interview with reporters, Wang Binggang, the leader of the supervision and consulting expert group for the National 863 Program’s major projects on energy conservation and new energy vehicles, referred to this mode as “online charging” The online charging mode can effectively solve the contradiction between battery quantity and range Wang Binggang stated. It is reported that currently, bus companies such as Hunan CSR Times Electric Vehicle, Youth Bus, and Hengtong Electric Vehicle are developing and promoting similar technologies.

As a Fortune 500 company, ABB’s business scope includes power and automation technology. In the field of electric vehicles in China, ABB is a supplier of DC drives, motors, programmable controller products, electric vehicle charging infrastructure, and energy storage products. In the field of charging infrastructure, ABB has not had a good opportunity, perhaps the latest “flash charging technology” can find some market space for ABB.
