UNITROL 1005-0011 voltage controller

1、 Product Overview
Application scope: UNITROL 1005-0011 is particularly suitable for hydraulic, steam turbine, and gas turbine generator sets, providing them with digital automatic voltage and excitation control systems.
Scalability: It extends the UNITOL 1000 product series to a smaller current range, with a maximum excitation current of up to 5 ADC, meeting a wider range of application needs.
2、 Technical features
Software and Models
Based on the same target software source code: sharing the same simulation model and target software source code with other products in the UNITOL 1000 series ensures product compatibility and stability.
Software version: UNITROL 1005-0011 provides ECO software package, including AVR/FCR/PF variable superposition, PF/VAR regulator, limited search, boost control/FRT detection and other functions, as well as soft start voltage matching and lightweight software package history recorder.
hardware feature
Power components: AVR output stage based on IGBT, supporting AC/DC input, with functions such as thyristor pry bar triggering and external fuse device tripping.
Measurement function: capable of measuring key parameters such as single-phase or three-phase machine voltage, single-phase machine current, excitation current, excitation voltage, and rectified input voltage.
Communication and Interface
Communication protocol: Supports Modbus TCP protocol, facilitating data exchange with other devices and systems.
Rich interfaces: Provides USB (power supply) and Ethernet interfaces, providing users with flexible data transmission methods.
Debugging and maintenance
Debugging Tools: We provide free CMT 1000 debugging and maintenance tools, as well as PID tuning tools, to help users quickly complete system debugging and optimization.
E-learning: Providing e-learning resources to help users better understand and master product features.
3、 Application Fields
UNITROL 1005-0011 is designed specifically for hydroelectric, steam turbine, and gas turbine generator sets, suitable for power stations that require efficient, stable, and reliable automation solutions. Its advanced technology and rich functions provide strong support for the automation control of power plants.
