UFC762AE101 3BHE006412R0101 Universal controller/servo drive module

1、 Product Overview
Model: UFC762AE101 3BHE006412R0101
Manufacturer: ABB
Type: Universal Controller/Servo Drive Module
2、 Main functions and features
Servo control:
The main function of this module is to control servo motors, including speed control, position control, and torque control, to achieve precise motion control.
High performance:
It has high-performance processing capability and feedback system, which can achieve high-precision and high dynamic response motion control.
Multi axis support:
Some modules support multi axis control, which can simultaneously drive multiple servo motors to meet the needs of multi axis motion control, achieving more complex motion trajectories and higher production efficiency.
Encoder interface:
It usually has an encoder interface to connect the encoder of the servo motor, providing position feedback and closed-loop control.
Communication interface:
Supports multiple communication interfaces, such as Ethernet, Modbus, CAN bus, etc., for easy data exchange and communication with other devices and control systems.
Self diagnosis and alarm:
It has self diagnostic function, which can detect system faults and generate alarms for timely maintenance measures.
Easy to configure and use:
Equipped with easy-to-use configuration and programming tools to reduce usage difficulty and maintenance costs. At the same time, it supports remote monitoring and maintenance functions, making it convenient for users to manage and maintain remotely.
Reliability and stability:
Designed to industrial standards, it has excellent stability and reliability, and can operate stably for a long time in harsh industrial environments.
Control accuracy:
The control accuracy is high, reaching ± 0.1% FS, ensuring the precision of motion control.
Input/output interface:
Provide multiple digital and analog input/output interfaces for connecting sensors, actuators, and other devices to achieve monitoring and control of industrial processes.
3、 Application Fields
UFC762AE101 3BHE006412R0101 is widely used in the field of industrial automation, including industrial robots, automated assembly lines, CNC machine tools, wind turbines, medical equipment, printing equipment, and other applications that require high-precision motion control.
4、 Product specifications
Dimensions: Approximately 144mm × 144mm × 102mm
Installation methods: board installation and wall mounted installation
Protection level: IP20
Material: Plastic and Metal
Weight: Approximately 1.5kg

Recently, ABB Group, headquartered in Switzerland, has attracted industry attention for a technology called “Flash Charging”. According to the information obtained from ABB (China) Enterprise Communication Department, “This technology was designed to be promoted globally

The system has been operating on the route between Geneva Airport and Palexpo Exhibition Center since May 26th and will continue until March 14th, 2014. The head of the company stated that this technology is suitable for ordinary cities, large cities, and mega cities seeking sustainable public transportation solutions. Used for high-frequency bus routes to alleviate traffic congestion in urban areas

According to ABB, this technology is equipped with a water-cooled lithium titanate oxide LTO battery pack with a service life of 10 years. There is a rooftop charging system at the station that can charge for 15 seconds at a power of 400 kilowatts. These charging systems are connected to the power grid and equipped with intermediate storage devices (supercapacitors) to reduce the impact of short-term high power on the grid. The fast charging point can charge buses up to 1.65 kWh. In addition, at the bus terminal, there is a 200 kW charger that can fully charge the battery in 3-4 minutes.

At present, pure electric buses using this technology can carry 135 people. When the vehicle stops at the station, it is located by infrared, and the charging point on the roof is connected to the moving arm controlled by laser after positioning. After completing a 15 second recharge, the vehicle continues to move forward without affecting the normal operation of the bus. Its concept is similar to that of a tram, but it does not require the installation of a complex network.

In addition to ABB, similar concepts of fast charging during driving are also being promoted by many companies in China. During an interview with reporters, Wang Binggang, the leader of the supervision and consulting expert group for the National 863 Program’s major projects on energy conservation and new energy vehicles, referred to this mode as “online charging” The online charging mode can effectively solve the contradiction between battery quantity and range Wang Binggang stated. It is reported that currently, bus companies such as Hunan CSR Times Electric Vehicle, Youth Bus, and Hengtong Electric Vehicle are developing and promoting similar technologies.

As a Fortune 500 company, ABB’s business scope includes power and automation technology. In the field of electric vehicles in China, ABB is a supplier of DC drives, motors, programmable controller products, electric vehicle charging infrastructure, and energy storage products. In the field of charging infrastructure, ABB has not had a good opportunity, perhaps the latest “flash charging technology” can find some market space for ABB.
