TB820V2 3BSE013208R1 ABB Module bus modem/cluster modem

1、 Product Overview
Model: TB820V2 3BSE013208R1
Brand: ABB
Type: Module bus modem or cluster modem (specific type may vary depending on the application)
2、 Main functions and applications
Module bus modem:
As the fiber optic interface of the module bus, TB820V2 3BSE013208R1 has both electrical and optical interfaces, logically belonging to the same bus.
It supports connecting multiple I/O modules to the electrical module bus and achieving local distribution of I/O clusters through fiber optic interfaces, making it particularly suitable for I/O stations that require more than 12 I/O modules.
Cluster modem:
In some applications, TB820V2 3BSE013208R1 serves as a cluster modem responsible for modulating and demodulating signals to ensure the accuracy and reliability of data transmission.
It may be used in conjunction with other ABB products such as PLCs, safety controllers, etc. to achieve complex industrial automation control.
3、 Technical features
High compatibility: Supports communication with parent controllers and PLCs on industry standard buses, ensuring system compatibility and scalability.
Flexible configuration: Equipped with a rotary switch for selecting cluster numbers (1 to 7) to accommodate different fiber optic module bus configurations.
Long distance transmission: In certain configurations (such as when used in conjunction with TB826), it is possible to achieve a bus distribution of optical modules up to 5000 meters, meeting the requirements of long-distance transmission.
4、 Application Fields
TB820V2 3BSE013208R1 ABB is widely used in the field of industrial automation, including but not limited to:
Factory automation: used to control various equipment and processes on the production line, improve production efficiency and product quality.
Building control: In intelligent building systems, automation control of lighting, air conditioning, security and other systems is achieved.
Data Center: Monitor and control environmental parameters such as temperature and humidity in the data center to ensure stable operation of equipment.
Renewable energy: In renewable energy generation systems such as solar and wind power, remote monitoring and intelligent control of power generation equipment are achieved.
