SPAD346C3 Integrated protection relay

1、 Product Overview
Type: Integrated protection relay
Brand: ABB
Model: SPAD346C3
2、 Main functions and features
Comprehensive protection function:
SPAD346C3 integrates multiple protection functions, including but not limited to overcurrent protection, overvoltage protection, undervoltage protection, overload protection, etc., which can effectively respond to various faults and abnormal situations in the power system and protect equipment from damage.
Quick response:
This relay has the characteristic of rapid response, which can quickly detect abnormal situations in the power system and take immediate protective measures to prevent further damage to the equipment.
Flexible configuration:
Users can adjust and set the protection parameters of SPAD346C3 according to their actual needs to adapt to different power systems and application scenarios. This flexibility ensures the effectiveness and reliability of the relay under various conditions.
Communication interface:
Usually equipped with communication interfaces, it can exchange and communicate data with the upper computer or monitoring system to achieve remote monitoring and management functions. This improves the automation level of the power system and reduces operation and maintenance costs.
High reliability and stability:
As a key protective equipment in the power system, SPAD346C3 has high reliability and stability, and can operate stably for a long time in harsh working environments. This ensures the continuity and safety of the power system.
3、 Application Fields
SPAD346C3 is suitable for various power systems, including but not limited to substations, power plants, distribution systems, etc. It is widely used to protect the safe operation of power equipment and systems, ensuring the stability and reliability of power supply.
4、 Technical specifications and parameters
Digital protection: adopting advanced digital signal processing technology to achieve high-precision protection and measurement functions.
Modular design: Easy to maintain and upgrade, different functional modules can be added or replaced as needed.
Multi channel input: supports input of multi-phase current and voltage, ensuring comprehensive monitoring and protection of all aspects of the power system.
5、 Summary
SPAD346C3 comprehensive protection relay is a powerful and stable power protection device. It provides reliable protection and security for the power system by integrating multiple protection functions and fast response mechanisms. Meanwhile, its flexible configuration options and communication interfaces enable it to adapt to different application scenarios and requirements.

Recently, ABB Group, headquartered in Switzerland, has attracted industry attention for a technology called “Flash Charging”. According to the information obtained from ABB (China) Enterprise Communication Department, “This technology was designed to be promoted globally

The system has been operating on the route between Geneva Airport and Palexpo Exhibition Center since May 26th and will continue until March 14th, 2014. The head of the company stated that this technology is suitable for ordinary cities, large cities, and mega cities seeking sustainable public transportation solutions. Used for high-frequency bus routes to alleviate traffic congestion in urban areas

According to ABB, this technology is equipped with a water-cooled lithium titanate oxide LTO battery pack with a service life of 10 years. There is a rooftop charging system at the station that can charge for 15 seconds at a power of 400 kilowatts. These charging systems are connected to the power grid and equipped with intermediate storage devices (supercapacitors) to reduce the impact of short-term high power on the grid. The fast charging point can charge buses up to 1.65 kWh. In addition, at the bus terminal, there is a 200 kW charger that can fully charge the battery in 3-4 minutes.

At present, pure electric buses using this technology can carry 135 people. When the vehicle stops at the station, it is located by infrared, and the charging point on the roof is connected to the moving arm controlled by laser after positioning. After completing a 15 second recharge, the vehicle continues to move forward without affecting the normal operation of the bus. Its concept is similar to that of a tram, but it does not require the installation of a complex network.

In addition to ABB, similar concepts of fast charging during driving are also being promoted by many companies in China. During an interview with reporters, Wang Binggang, the leader of the supervision and consulting expert group for the National 863 Program’s major projects on energy conservation and new energy vehicles, referred to this mode as “online charging” The online charging mode can effectively solve the contradiction between battery quantity and range Wang Binggang stated. It is reported that currently, bus companies such as Hunan CSR Times Electric Vehicle, Youth Bus, and Hengtong Electric Vehicle are developing and promoting similar technologies.

As a Fortune 500 company, ABB’s business scope includes power and automation technology. In the field of electric vehicles in China, ABB is a supplier of DC drives, motors, programmable controller products, electric vehicle charging infrastructure, and energy storage products. In the field of charging infrastructure, ABB has not had a good opportunity, perhaps the latest “flash charging technology” can find some market space for ABB.
