PU516 3BSE013064R1 ABB communication module

1、 Product Overview
PU516 3BSE013064R1 ABB is an engineering board or communication module with MB300 and RS-232 ports, suitable for 5V 32-bit 33MHz PCI bus. This device integrates multiple functions and is suitable for high impact, high vibration, and high humidity environments. It has a wide operating temperature range from -40 ° C to+100 ° C.
2、 Main characteristics
Port configuration:
Equipped with one MB300 port and one RS-232 port, supporting multiple communication protocols and data transmission methods.
compatibility:
Suitable for 5V 32-bit 33MHz PCI bus, with good compatibility and scalability.
Environmental adaptability:
Suitable for high impact, high vibration, and high humidity environments, with excellent stability and durability.
Working temperature range:
The working temperature range is -40 ° C to+100 ° C, suitable for various extreme environments.
Memory configuration:
With 16Mbyte of memory, it provides ample space for data processing and storage.
Power supply and protection:
The power module provides stable power output, supports multiple power output options, and has overload and short circuit protection functions.
3、 Application Fields
PU516 3BSE013064R1 ABB is widely used in industrial automation, process control, power systems and other fields. Specifically, it can be used for:
Data transmission and communication in industrial automation systems.
Monitoring and control of the power system to improve its stability and safety.
Data collection and processing in process control to ensure the smooth progress of the production process.

ABB, the world’s leading power and automation technology group, announced that it will provide a 363 kV high-voltage isolated circuit breaker with an all fiber current transformer for the Shaanxi Fuping Intelligent Substation. This circuit breaker combines three substation functions: isolation, circuit breaking, and current measurement, reducing the substation’s footprint by up to 70%. At the same time, it is also the world’s first isolated circuit breaker equipped with fiber optic current transformers at this high voltage level.

All fiber current transformers will replace traditional current transformers used for measurement and protection in integrated intelligent switches, and create conditions for grid automation. In the northwest region of China, the voltage level of 363 kV is the most common. This application is also the first commercial application of the isolated circuit breaker technology at this voltage level.

As part of the new generation intelligent substation project planned by State Grid Corporation of China in 2015, Shaanxi Fuping Intelligent Substation will provide electricity for the rapidly developing industrial belt around Fuping County, Shaanxi Province. The project aims to utilize the most advanced technology to enable remote control, protection, automation, monitoring, and analysis of substations, while reducing operating costs, footprint, and environmental impact. At the same time, the new generation of smart substations can make the national power grid more efficient, flexible, and reliable, laying the foundation for China’s increasing integration of renewable energy into the grid. According to data from the National Energy Administration of China, the cumulative installed capacity of renewable energy generation in China exceeded 400 million kilowatts in 2014, accounting for over 30% of the total installed capacity of electricity, continuing to maintain its position as the world’s largest country in terms of renewable energy utilization scale.

ABB has been providing the most advanced technology for China’s power infrastructure construction, supporting a stronger, smarter, and greener power grid through our equipment. This once again demonstrates that leading technology will be the key to ABB’s market leadership position under the ‘new stage’ strategy, “said Yuker, President of ABB’s Power Products Business

As a pioneer in isolated circuit breaker technology, ABB has installed approximately 1800 isolated circuit breakers worldwide. Since 2010, ABB has been operating a test project in Sweden for 420 kV high-voltage isolated circuit breakers equipped with all fiber current transformers, accumulating a wealth of experience in this field. This innovative technology not only integrates three types of substation functions, but also provides digital output of substation and grid automation related data, and is fully integrated into the smart grid based on the latest IEC digital communication standard (IEC 61850-9-2LE).

This technology can replace traditional switchgear and reduce the footprint of air isolation switches in substations by 70%. Not only that, it can also help high-voltage substations reduce several tons of equipment, improve substation safety, reduce installation time, save design, operation, and maintenance costs, and reduce environmental impact.

By the end of 2015, State Grid Corporation of China plans to build a new round of 50 next-generation smart substations and vigorously promote the construction of smart grids. ABB will provide innovative high-voltage isolation circuit breakers equipped with full fiber current transformers, intelligent medium voltage switchgear, and transformer intelligent electronic components (such as innovative self drying respirators) for 13 of the smart substations, helping to create a more efficient and reliable smart grid and achieve the “interconnection of goods, services, and people”.

ABB ranks among the Fortune Global 500 and is a leading enterprise in the fields of power and automation technology. ABB is committed to helping customers in the fields of power, industry, transportation, and infrastructure improve their performance while reducing their impact on the environment. ABB Group has operations in nearly 100 countries worldwide and employs 140000 people. ABB has comprehensive business activities in China, including research and development, manufacturing, sales, and engineering services. It has 19000 employees, 39 local enterprises, and a sales and service network covering 126 cities across the country.
