DSAI130D ABB Input/Output (I/O) Module

1、 Product Overview
DSAI130D ABB module is a high-performance, multifunctional input/output (I/O) module produced by ABB, belonging to ABB’s S-series I/O module series. This module has a compact design and excellent performance, and is widely used in various fields such as industrial automation, process control, energy management, environmental monitoring, and laboratory instruments.
2、 Main functions and features
Digital signal processing: The DSAI130D module is mainly used to receive and process digital signals from various devices (such as switches, sensors, etc.), and monitor the status or conditions of the devices in real time.
Efficient and reliable: Using high-quality electronic components and manufacturing processes, it ensures stable operation even in harsh industrial environments, with high reliability and stability.
Multi channel design: This module typically has multiple independent digital or analog input channels, which can connect multiple signal sources to meet the needs of complex applications.
Real time control: Based on the received signals, the module can control the machine or equipment to perform corresponding actions in real time, ensuring the continuity and efficiency of the production process.
Easy to operate and maintain: With a simple and easy-to-use interface and operation method, it is convenient for users to set up, debug, and use. At the same time, the design of the module makes it easy to maintain and replace, reducing operating costs.
Communication interface: Supports multiple communication protocols (such as Profibus DP, FOUNDATION Fieldbus, etc.), facilitating connection and data exchange with ABB control systems or other devices.
Security protection: Modules usually have a certain level of protection (such as IP65), which can adapt to various complex and harsh working environments, ensuring the safe operation of equipment.
3、 Technical parameters
Module size: 87 mm x 46 mm x 23 mm
Number of input channels: Depending on the specific model, for example, an analog input module may have 16 channels
Resolution: For analog input modules, typically 12 bits
Input range: Depending on the signal type, for example, analog input modules may support ± 76.5 mV
Input impedance: High input impedance, such as 2 M Ω
Sampling rate: Supports multiple sampling rates, such as 250 Hz, 500 Hz, 1 kHz, etc
Filtering time: Provides multiple filtering time options to meet different application requirements
Power supply voltage: typically 24 VDC
Power consumption: relatively low, such as 3 W
Working temperature: a wide range of working temperatures, such as -20 ° C to 60 ° C
4、 Application Fields
The DSAI130D ABB module is highly favored for its excellent performance and wide range of application areas. It is often used in the following fields:
Industrial automation: used for monitoring and controlling production processes, equipment, and facilities to improve production efficiency and quality.
Manufacturing industry: including automotive manufacturing, electronics manufacturing, food processing, and pharmaceuticals, to achieve automated manufacturing processes.
Power industry: Monitor power equipment, power systems, and generators to ensure the stable operation of the power system.
Building automation: Control lighting, HVAC, safety systems, elevators and other equipment to improve the energy efficiency and comfort of buildings.
Medical equipment: Control medical imaging equipment, surgical robots, and laboratory equipment to ensure the accuracy and safety of medical processes.
Environmental monitoring: Control and monitor parameters such as atmosphere, water quality, soil, and noise levels to provide data support for environmental protection.
In summary, the DSAI130D ABB module is a powerful and stable industrial automation equipment that can meet various complex and diverse application needs.

PFSK15 ABB

ABB, the world’s leading power and automation technology group, announced that it will provide a 363 kV high-voltage isolated circuit breaker with an all fiber current transformer for the Shaanxi Fuping Intelligent Substation. This circuit breaker combines three substation functions: isolation, circuit breaking, and current measurement, reducing the substation’s footprint by up to 70%. At the same time, it is also the world’s first isolated circuit breaker equipped with fiber optic current transformers at this high voltage level.

All fiber current transformers will replace traditional current transformers used for measurement and protection in integrated intelligent switches, and create conditions for grid automation. In the northwest region of China, the voltage level of 363 kV is the most common. This application is also the first commercial application of the isolated circuit breaker technology at this voltage level.

As part of the new generation intelligent substation project planned by State Grid Corporation of China in 2015, Shaanxi Fuping Intelligent Substation will provide electricity for the rapidly developing industrial belt around Fuping County, Shaanxi Province. The project aims to utilize the most advanced technology to enable remote control, protection, automation, monitoring, and analysis of substations, while reducing operating costs, footprint, and environmental impact. At the same time, the new generation of smart substations can make the national power grid more efficient, flexible, and reliable, laying the foundation for China’s increasing integration of renewable energy into the grid. According to data from the National Energy Administration of China, the cumulative installed capacity of renewable energy generation in China exceeded 400 million kilowatts in 2014, accounting for over 30% of the total installed capacity of electricity, continuing to maintain its position as the world’s largest country in terms of renewable energy utilization scale.

ABB has been providing the most advanced technology for China’s power infrastructure construction, supporting a stronger, smarter, and greener power grid through our equipment. This once again demonstrates that leading technology will be the key to ABB’s market leadership position under the ‘new stage’ strategy, “said Yuker, President of ABB’s Power Products Business

As a pioneer in isolated circuit breaker technology, ABB has installed approximately 1800 isolated circuit breakers worldwide. Since 2010, ABB has been operating a test project in Sweden for 420 kV high-voltage isolated circuit breakers equipped with all fiber current transformers, accumulating a wealth of experience in this field. This innovative technology not only integrates three types of substation functions, but also provides digital output of substation and grid automation related data, and is fully integrated into the smart grid based on the latest IEC digital communication standard (IEC 61850-9-2LE).

This technology can replace traditional switchgear and reduce the footprint of air isolation switches in substations by 70%. Not only that, it can also help high-voltage substations reduce several tons of equipment, improve substation safety, reduce installation time, save design, operation, and maintenance costs, and reduce environmental impact.

By the end of 2015, State Grid Corporation of China plans to build a new round of 50 next-generation smart substations and vigorously promote the construction of smart grids. ABB will provide innovative high-voltage isolation circuit breakers equipped with full fiber current transformers, intelligent medium voltage switchgear, and transformer intelligent electronic components (such as innovative self drying respirators) for 13 of the smart substations, helping to create a more efficient and reliable smart grid and achieve the “interconnection of goods, services, and people”.

ABB ranks among the Fortune Global 500 and is a leading enterprise in the fields of power and automation technology. ABB is committed to helping customers in the fields of power, industry, transportation, and infrastructure improve their performance while reducing their impact on the environment. ABB Group has operations in nearly 100 countries worldwide and employs 140000 people. ABB has comprehensive business activities in China, including research and development, manufacturing, sales, and engineering services. It has 19000 employees, 39 local enterprises, and a sales and service network covering 126 cities across the country.
