LD 800HSE 3BDH000320R0101 Industrial communication module

1、 Product Overview
LD 800HSE 3BDH000320R0101 is a powerful industrial communication module that supports seamless connectivity and data exchange between various devices and systems. It adopts high-speed Ethernet technology to ensure fast and reliable data transmission, suitable for demanding industrial applications.
2、 Main characteristics
Efficient communication:
This module supports high-speed Ethernet communication, allowing for fast and reliable data transmission, ensuring real-time communication between different components of industrial networks.
Wide compatibility:
Compatible with Ethernet/IP protocol, this is a widely used protocol for industrial automation that can seamlessly integrate with other devices and systems that support Ethernet/IP, enabling efficient data exchange and system integration.
Real time diagnosis and monitoring:
Providing real-time status information and performance data, allowing for proactive maintenance and troubleshooting, helps minimize downtime and optimize the overall performance of industrial networks.
Easy to install and configure:
Featuring a user-friendly interface and supporting various configuration options, allowing seamless integration into existing industrial networks.
Powerful security features:
Equipped with powerful security features to prevent unauthorized access and ensure data integrity and security.
Redundant design:
Suitable for redundant use, where the corresponding H1 ports of two linked devices are connected to one H1 link. The independent redundant link between the main link device and the auxiliary link device ensures reliable fault transfer and redundant monitoring.
3、 Technical specifications
Power supply voltage: 24 V DC (+-20%)
Size: 47 x 131 x 111 millimeters
Weight: Approximately 0.4 kg
Installation: Installed on a 35 mm DIN rail (DIN EN 50 022)
Signal processing capability: For systems after 800xA SV5.1, the signal transmission between HSE and H1 can process up to 160 signals per second between all four H1 links and the HSE network, while 4 * 16 client/server connections can be used in parallel.
4、 Application Fields
LD 800HSE 3BDH000320R0101 is not only suitable for equipment connection within a single factory, but also for equipment connection across multiple locations. It is widely used in industrial automation, process control, intelligent manufacturing and other fields, providing efficient and reliable data transmission and system integration solutions for industrial networks.
