ACS580-04-505A-4 frequency converter

1、 Basic parameters
Suitable motor power: heavy load 200KW, light load 250KW.
Rated voltage: three-phase AC380-415V.
Rated current: 2.6A (although the specific current may vary depending on actual usage).
Frequency: Intermediate frequency.
Output type: Unknown (but usually the output type of the frequency converter is PWM control).
Main circuit working mode: voltage type.
Switching mode: PWM control.
Control method: Voltage vector control.
Output voltage regulation method: PWM control.
Filter: Built in 1A+1B filter.
Number of power phases: Three phases.
Power supply voltage: low voltage.
2、 Physical characteristics
External dimensions: There are various specifications, such as 420mm × 282mm × 230mm (but specific dimensions may vary depending on different batches or customization requirements).
Weight: There are also various specifications, such as 150kg (but the specific weight may also vary depending on different batches or customization requirements).
Appearance specifications: IP21, IP55 (may refer to protection level).
Noise: The specific noise level may vary depending on different working environments and operating conditions.
3、 Optional accessories and interfaces
Control panel: including basic control panel (ACS-CP-C), advanced Chinese control panel (ACS-CP-D, G version and below cannot be used for ACS350), etc.
Connection lines: such as cabinet control panel connection lines (ACS/H-CP-EXT), etc.
Installation components: such as control panel installation components.
Bus adapters: including DeviceNet Adapter (+K451 FDNA-01), Profibus DP Adapter (+K454 FPBA-01), CANOpen Adapter (+K457 FCAN-01), Modbus Adapter (+K458 FMBA-01), etc.
Other optional accessories: such as electric potentiometer (MPOT-01), speed feedback encoder (MTAC-01), flash downloader (MFDT-01), etc.
4、 Application and Characteristics
Application scope: Widely used in various fields such as chemical fiber industry, glass industry, automatic feeding and batching system for electric arc furnaces, and intelligent control of elevators. At the same time, it is also applicable to industries such as CNC machine tool control, automotive production lines, papermaking, and elevators to improve process level and product quality.
Main features:
Built in 32-bit or 16 bit microprocessor with multiple arithmetic logic operations and intelligent control functions.
The output frequency accuracy is high, reaching 0.1%~0.01%.
There are comprehensive detection and protection measures in place to ensure the stable operation of the equipment.
Adopting ABB’s revolutionary “Direct Torque Control (DTC)” technology, it can accurately control the motor state and quickly respond to load changes.
It can significantly reduce energy consumption, generally reducing the energy consumption of pumps, fans, and compressors by half.
